Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 50 | ₹ 4,315.66000 | ₹ 2,15,783.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | TP-POE | |
| IC Encapsulation Type | Retail Package | |
| Availability Status | Active | |
| Device Type Classification | Passive Injector | |
| Supply Input Volts | 90 ~ 264 VAC | |
| Connection Port Total | 1 | |
| Delivery Output Volts | 48V | |
| Output Delivery Amps | 500 mA | |
| Per-Port Power Delivery | 24W | |
| Regulatory Standards Met | IEEE802.3af, IEEE802.3at | |
| Transfer Speed Mbps | 10/100/1000 Mbps | |
| Key Product Highlights | OCP, OVP, SCP | |
| Ambient Temp Range | -30°C ~ 60°C | |
| Performance Efficiency Rating | 85% | |
| Attachment Mounting Style | Desktop | |
| Package Size Specs | 3.40" L x 3.00" W x 1.40" H (86.4mm x 76.2mm x 35.6mm) | |
| Certification Body | FCC, TUV | |
| Compliance Standard ID | 60950-1 |
Description
Complies with the criteria of entities acknowledged as FCC, TUV. Complies with the standards specified as IEEE802.3af, IEEE802.3at. Yields output current measured at 500 mA. Delivers a data transfer rate measured at 10/100/1000 Mbps for rapid operations. Demonstrates a sampling rate capability indicated as 10/100/1000 Mbps. Offers an efficiency rating calculated at 85%. Equipped with features categorized as OCP, OVP, SCP. The input voltage established at 90 ~ 264 VAC for reliable performance. Mounting configuration Desktop for structural stability. Overall number of ports 1 for communication or connectivity. Temperature range -30°C ~ 60°C for environmental conditions impacting thermal efficiency. Voltage 48V for optimal output electric potential. Type of housing Retail Package for safeguarding or transporting components. Power distribution per port 24W for setups with multiple ports. Product status Active concerning availability and lifecycle. Classification series for the product or component TP-POE. Details on package size 3.40" L x 3.00" W x 1.40" H (86.4mm x 76.2mm x 35.6mm) for electrical or mechanical components. Measurement dimensions 3.40" L x 3.00" W x 1.40" H (86.4mm x 76.2mm x 35.6mm) for component specifications. Standard compliance code 60950-1 for regulations. Current supply level 90 ~ 264 VAC for electrical parameters. Type classification Passive Injector for specifications. Input voltage 90 ~ 264 VAC required for devices. The output voltage 48V for electrical systems.
