Description

Supports an AC input voltage rated at 320 ~ 575 VAC (3 Phase) for extensive operational compatibility. Perfectly designed for situations involving ITE (Commercial), Laboratory. Complies with the criteria of entities acknowledged as CB, CE, CSA, EN, IEC, UL. Supplies peak output current defined as 40A. Allows for a maximum DC input voltage of 815V. Requires a minimum DC input voltage of 450V. Offers an efficiency rating calculated at 96%. Equipped with features categorized as Adjustable Output, IP20, PFC, Universal Input. Configured with AC or DC input type for diverse applications. The input voltage established at 320 ~ 575 VAC (3 Phase) for reliable performance. Overall outputs 1 for device connections. Temperature range -40°C ~ 70°C (With Derating) for environmental conditions impacting thermal efficiency. Voltage 24V for optimal output electric potential. Type of housing Box for safeguarding or transporting components. Power measured in watts 960W for optimal operation. Product status Active concerning availability and lifecycle. Classification series for the product or component RACPRO1-T960 (960W). Details on package size 6.13" L x 3.15" W x 5.31" H (155.7mm x 80.0mm x 135.0mm) for electrical or mechanical components. Measurement dimensions 6.13" L x 3.15" W x 5.31" H (155.7mm x 80.0mm x 135.0mm) for component specifications. Standard compliance code 61010-1; 62368-1 for regulations. Isolation voltage 3.5 kV for electrical safety. Output 1 voltage 24V across different outputs.
