Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | GT-86121-1209-W2 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Active Area Utilization | North America | |
| Physical Form Factor | Wall Mount (Class II) | |
| Entry Signal Category | Fixed Blade | |
| Supply Input Volts | 90 ~ 264 VAC | |
| Delivery Output Volts | 9V | |
| Peak Output Current | 1.33A | |
| Wattage Power Level | 12 W | |
| Standby Power Usage | 75mW (Max) | |
| Optical Polarization Mode | Positive Center | |
| Intended Uses | ITE (Commercial) | |
| Performance Efficiency Rating | Level VI | |
| Ambient Temp Range | 0°C ~ 50°C | |
| Exit Plug Type | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 11.0mm | |
| Power Cord Extension | 59" (1.50m) | |
| Source Plug Type | NEMA 1-15P | |
| Key Product Highlights | - | |
| Package Size Specs | 2.72" L x 1.13" W x 2.26" H (69.0mm x 28.8mm x 57.3mm) | |
| Certification Body | CB, cULus, EAC, LPS, PSE, UKRSepro, VCCI | |
| Compliance Standard ID | 60950-1 |
Description
Perfectly designed for situations involving ITE (Commercial). Complies with the criteria of entities acknowledged as CB, cULus, EAC, LPS, PSE, UKRSepro, VCCI. Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Offers a cord length measuring 59" (1.50m). Supplies peak output current defined as 1.33A. Offers an efficiency rating calculated at Level VI. Utilizes a form factor outlined as Wall Mount (Class II). Includes a NEMA 1-15P input connector for seamless interaction. Configured with Fixed Blade input type for diverse applications. The input voltage established at 90 ~ 264 VAC for reliable performance. Power consumption during standby 75mW (Max) for energy efficiency. Temperature range 0°C ~ 50°C for environmental conditions impacting thermal efficiency. Connector Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 11.0mm for linking device output. Voltage 9V for optimal output electric potential. Type of housing Bulk for safeguarding or transporting components. The Positive Center type of polarization for optical or RF applications. Power measured in watts 12 W for optimal operation. Product status Active concerning availability and lifecycle. Space utilized North America for the application or implementation of the product. Classification series for the product or component GT-86121-1209-W2. Details on package size 2.72" L x 1.13" W x 2.26" H (69.0mm x 28.8mm x 57.3mm) for electrical or mechanical components. Measurement dimensions 2.72" L x 1.13" W x 2.26" H (69.0mm x 28.8mm x 57.3mm) for component specifications. Standard compliance code 60950-1 for regulations. Current supply level 90 ~ 264 VAC for electrical parameters. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. Input voltage 90 ~ 264 VAC required for devices. The output voltage 9V for electrical systems.
