Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 2,269.50000 | ₹ 2,269.50 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | SYS1561-Wxx (12W) | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Active Area Utilization | North America | |
| Physical Form Factor | Wall Mount (Class II) | |
| Entry Signal Category | Fixed Blade | |
| Supply Input Volts | 90 ~ 264 VAC | |
| Delivery Output Volts | 12V | |
| Peak Output Current | 1A | |
| Wattage Power Level | 12 W | |
| Standby Power Usage | - | |
| Optical Polarization Mode | - | |
| Intended Uses | ITE (Commercial) | |
| Performance Efficiency Rating | Level VI | |
| Ambient Temp Range | 0°C ~ 40°C | |
| Exit Plug Type | Rectangular, 6 Position | |
| Power Cord Extension | 59" (1.50m) | |
| Source Plug Type | NEMA 1-15P | |
| Key Product Highlights | - | |
| Package Size Specs | 2.52" L x 1.77" W x 1.18" H (64.0mm x 45.0mm x 30.0mm) | |
| Certification Body | BIS, BSMI, CB, CCC, CE, cULus, EAC, FCC, GS, IECEE, KC, PSE, RCM, SAA, S-MARK, UKCA | |
| Compliance Standard ID | 62368-1 |
Description
Perfectly designed for situations involving ITE (Commercial). Complies with the criteria of entities acknowledged as BIS, BSMI, CB, CCC, CE, cULus, EAC, FCC, GS, IECEE, KC, PSE, RCM, SAA, S-MARK, UKCA. Offers a cord length measuring 59" (1.50m). Supplies peak output current defined as 1A. Offers an efficiency rating calculated at Level VI. Utilizes a form factor outlined as Wall Mount (Class II). Includes a NEMA 1-15P input connector for seamless interaction. Configured with Fixed Blade input type for diverse applications. The input voltage established at 90 ~ 264 VAC for reliable performance. Temperature range 0°C ~ 40°C for environmental conditions impacting thermal efficiency. Connector Rectangular, 6 Position for linking device output. Voltage 12V for optimal output electric potential. Type of housing Bulk for safeguarding or transporting components. Power measured in watts 12 W for optimal operation. Product status Active concerning availability and lifecycle. Space utilized North America for the application or implementation of the product. Classification series for the product or component SYS1561-Wxx (12W). Details on package size 2.52" L x 1.77" W x 1.18" H (64.0mm x 45.0mm x 30.0mm) for electrical or mechanical components. Measurement dimensions 2.52" L x 1.77" W x 1.18" H (64.0mm x 45.0mm x 30.0mm) for component specifications. Standard compliance code 62368-1 for regulations. Current supply level 90 ~ 264 VAC for electrical parameters. Input voltage 90 ~ 264 VAC required for devices. The output voltage 12V for electrical systems.
