Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Inductor Core Material | Toroid | |
| Vendor Package Type | TX 14 x 9 x 5 | |
| Construction Material Type | 4C65 | |
| Circular Measurement | 0.561" (14.25mm) | |
| Inductance per Turn Factor | - | |
| Accuracy Tolerance Percentage | ±30% | |
| Spacing Gap Measurement | Ungapped | |
| Effective Mu Permeability | - | |
| Starting Permeability Mu | - | |
| Magnetic Core Density Factor | 2.84 | |
| Magnetic Effective Length | 35.0 | |
| Magnetic Effective Area | 12.3 | |
| Min Core Cross-Section Area | - | |
| Magnetic Volume Efficiency | 430.0 | |
| Surface Finish Type | Epoxy | |
| Vertical Dimension | 0.207" (5.25mm) | |
| Linear Length Dimension | - | |
| Horizontal Width Dimension | - |
Description
Defines the core density factor represented as 2.84 mm⁻¹ for magnetic calculations. Utilizes the core type categorized as Toroid. Offers diameter noted at 0.561" (14.25mm). Shows effective area measured at 12.3 mm². Presents an effective length measured at 35.0 mm. Features an effective magnetic volume measured at 430.0 mm³. Describes the finish as Epoxy. Designed with a Ungapped gap for precise mechanical or electrical alignment. Features a height of 0.207" (5.25mm) for accurate dimensional precision. Type of construction material 4C65 for durability and efficiency. Type of housing Bulk for safeguarding or transporting components. Type of package TX 14 x 9 x 5 that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Supplier package type TX 14 x 9 x 5 for component selection. Precision tolerance level ±30% in manufacturing processes.
