Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 82930 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Device Type Classification | Permanent Magnet | |
| Electromagnetic Coil Design | Bipolar | |
| Rated Operating Voltage | 10.4VDC | |
| Ampere Capacity Rating | 480 mA | |
| Revolution Step Count | 48.0 | |
| Stepper Motor Step Degrees | 7.5° | |
| Precision Level | - | |
| Holding Torque Rating | 25.5 / 180 | |
| Package Size Specs | Round - 2.280" Dia (57.80mm) | |
| Motor Frame Standard | - | |
| Shaft Rod Width | 0.157" (4.00mm) | |
| Shaft Bearing Total Length | 0.630" (16.00mm) | |
| Screw Hole Pitch | 2.630" (66.68mm) | |
| Lead Termination Type | Wire Leads | |
| Ambient Temp Range | - | |
| Inductor Resistance Value | 22.3 Ohms | |
| Key Product Highlights | Round Shaft |
Description
Features a coil resistance measured at 22.3 Ohms to maintain consistent electromagnetic performance. Designed with a coil type classified as Bipolar for optimal electrical efficiency. Sets the ampere rating to 480 mA. Defines the shaft diameter as 0.157" (4.00mm). Equipped with features categorized as Round Shaft. Total length of the shaft and bearing 0.630" (16.00mm) for smooth assembly. Spacing between mounting holes 2.630" (66.68mm) for correct alignment. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component 82930. Details on package size Round - 2.280" Dia (57.80mm) for electrical or mechanical components. Measurement dimensions Round - 2.280" Dia (57.80mm) for component specifications. Step angle 7.5° related to stepper motors. Total steps per revolution 48.0 for rotating mechanisms. Type of termination Wire Leads for connector or device. Torque retention 25.5 / 180 in oz-in/mNm for reliability. Type classification Permanent Magnet for specifications. The operating voltage rating of the device 10.4VDC.
