Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | PANdrive™ | |
| IC Encapsulation Type | Bulk | |
| Device Type Classification | DC Motor | |
| Primary Function Mode | Servomotor | |
| Electric Motor Design | Brushless (BLDC) | |
| Rated Operating Voltage | 24VDC | |
| Revolutions Per Minute | 4000 RPM | |
| Nominal Torque Value | 25.49 / 180 | |
| Nominal Power Rating | - | |
| Position Encoder Category | - | |
| Package Size Specs | Square - 1.654" x 1.654" (42.00mm x 42.00mm) | |
| Shaft Rod Width | 0.197" (5.00mm) | |
| Shaft Bearing Total Length | 0.866" (22.00mm) | |
| Screw Hole Pitch | 0.988" (25.10mm) | |
| Lead Termination Type | Wire Leads with Connector | |
| Key Product Highlights | Integrated Controller, Flatted Shaft | |
| Speed Reduction Gear Ratio | - | |
| Peak Instant Torque | - | |
| Ambient Temp Range | -20°C ~ 40°C |
Description
Defines the shaft diameter as 0.197" (5.00mm). Equipped with features categorized as Integrated Controller, Flatted Shaft. Engineered with Servomotor features for versatile component usage. Total length of the shaft and bearing 0.866" (22.00mm) for smooth assembly. Type of motor Brushless (BLDC) for mechanical functionality. Spacing between mounting holes 0.988" (25.10mm) for correct alignment. Temperature range -20°C ~ 40°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. The RPM value 4000 RPM for motors or mechanical devices. Classification series for the product or component PANdrive™. Details on package size Square - 1.654" x 1.654" (42.00mm x 42.00mm) for electrical or mechanical components. Measurement dimensions Square - 1.654" x 1.654" (42.00mm x 42.00mm) for component specifications. Type of termination Wire Leads with Connector for connector or device. Designated torque 25.49 / 180 in oz-in/mNm for classification. Type classification DC Motor for specifications. The operating voltage rating of the device 24VDC.
