Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Nitrogen8M | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Central CPU Unit | ARM® Cortex®-A53, Cortex®-M4 | |
| Operational Speed Rating | 400MHz, 1.8GHz | |
| Processor Core Number | 1/4 | |
| Wattage Power Level | - | |
| Thermal Management Method | - | |
| Package Size Specs | 3.228" x 1.969" (81.99mm x 50.01mm) | |
| Device Size Standard | SMARC2.1.1 | |
| Expansion Slot Bus Type | Audio, CAN, GPIO, I2C, LVDS, MIPI CSI, MIPI DSI, PCIe, UART, Wi-Fi/Bluetooth | |
| Installed RAM Volume | 1GB/0GB | |
| Memory Bus Interface | eMMC, SPI | |
| Display Video Ports | LVDS, MIPI CSI, MIPI DSI | |
| Network Ethernet Standard | GbE | |
| USB Interface Version | USB 2.0 (3) | |
| Serial Port Standards | - | |
| Digital Input/Output Pins | - | |
| Analog Signal In to Out | - | |
| System Monitor Timer | No | |
| Included Components | - | |
| Ambient Temp Range | 0°C ~ 70°C |
Description
Includes the core processor identified as ARM® Cortex®-A53, Cortex®-M4 for swift processing. Conforms to the Ethernet standard specified at GbE. Has an expansion slot or bus type specified at Audio, CAN, GPIO, I2C, LVDS, MIPI CSI, MIPI DSI, PCIe, UART, Wi-Fi/Bluetooth. Shows a form factor labeled as SMARC2.1.1. The total number of cores is 1/4 for processors or cables. Temperature range 0°C ~ 70°C for environmental conditions impacting thermal efficiency. Type of housing Tray for safeguarding or transporting components. Product status Active concerning availability and lifecycle. The total capacity of the installed RAM 1GB/0GB for optimal computing performance. Classification series for the product or component Nitrogen8M. Details on package size 3.228" x 1.969" (81.99mm x 50.01mm) for electrical or mechanical components. Measurement dimensions 3.228" x 1.969" (81.99mm x 50.01mm) for component specifications. Operational speed 400MHz, 1.8GHz for mechanical or data tasks. Connection interface eMMC, SPI for storage integration. Version of USB USB 2.0 (3) for connectivity. Video interfaces LVDS, MIPI CSI, MIPI DSI for display or graphics output. The timer No used for monitoring the system.
