Attribute
Description
Manufacturer Part Number
JF15RP2CC
Manufacturer
Description
ULTRA THIN TACTILE/ILLUMINATED/PC
Manufacturer Lead Time
27 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.05A @ 24VDC | |
| Actuator Type | Round Button | |
| Mounting Type | Through Hole | |
| Actuator Height off PCB, from Pins | 5.08mm | |
| Actuator Orientation | Top Actuated | |
| Termination Style | PC Pin | |
| Outline | 22.80mm x 17.70mm | |
| Illumination | Illuminated | |
| Illumination Voltage (Nominal) | 1.7 VDC | |
| Illumination Type, Color | LED, Red | |
| Operating Force | 300gf | |
| Ingress Protection | - |
