Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 07 | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount | |
| Electrical Pathway | SPST | |
| Switch Operation Mode | Off-Mom | |
| Ampere Capacity Rating | 15A (AC/DC) | |
| AC Voltage Max | 115 V | |
| DC Voltage Max | 28 V | |
| Activator Mechanism Type | Standard Round | |
| Activator Arm Length | - | |
| Backlighting Feature | Non-Illuminated | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Lead Termination Type | Quick Connect - 0.250" (6.3mm) | |
| Mount Cutout Specs | Circular - 12.40mm Dia | |
| Insulator Thread Pattern | M12 x 0.75 | |
| Dust Water Resistance Rating | IP65 - Dust Tight, Water Resistant | |
| Key Product Highlights | - | |
| Ambient Temp Range | -35°C ~ 60°C |
Description
Incorporates a Standard Round actuator type to fulfill the desired function. Crafted with a bushing thread dimension of M12 x 0.75 to guarantee a secure connection. Configured for circuit type described as SPST. Sets the ampere rating to 15A (AC/DC). Provides Non-Illuminated brightness for improved visibility. Rated with IP IP65 - Dust Tight, Water Resistant to safeguard against dust and moisture penetration. Mounting configuration Panel Mount for structural stability. Temperature range -35°C ~ 60°C for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Specifications of the cutout Circular - 12.40mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component 07. Modification in operation mode Off-Mom for electrical optimization. Type of termination Quick Connect - 0.250" (6.3mm) for connector or device. The highest AC voltage specification 115 V for the device. The highest DC voltage specification 28 V for components.
