Stock:
Distributor: 69
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 18 | ₹ 897.12000 | ₹ 16,148.16 |
| 100 | ₹ 879.32000 | ₹ 87,932.00 |
| 250 | ₹ 845.50000 | ₹ 2,11,375.00 |
| 500 | ₹ 759.17000 | ₹ 3,79,585.00 |
| 1000 | ₹ 750.27000 | ₹ 7,50,270.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 110 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount | |
| Electrical Pathway | SPST | |
| Switch Operation Mode | On-Off | |
| Ampere Capacity Rating | 6A (AC/DC) | |
| AC Voltage Max | 125 V | |
| DC Voltage Max | 125 V | |
| Activator Mechanism Type | Standard Round | |
| Activator Arm Length | 12.70mm | |
| Backlighting Feature | Non-Illuminated | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Lead Termination Type | Solder Lug | |
| Mount Cutout Specs | Circular - 12.70mm Dia | |
| Insulator Thread Pattern | 15/32-32 | |
| Dust Water Resistance Rating | - | |
| Key Product Highlights | - | |
| Ambient Temp Range | -17.8°C ~ 65.6°C |
Description
Engineered with an actuator length of 12.70mm to provide sufficient interaction range. Incorporates a Standard Round actuator type to fulfill the desired function. Crafted with a bushing thread dimension of 15/32-32 to guarantee a secure connection. Configured for circuit type described as SPST. Sets the ampere rating to 6A (AC/DC). Provides Non-Illuminated brightness for improved visibility. Mounting configuration Panel Mount for structural stability. Temperature range -17.8°C ~ 65.6°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Circular - 12.70mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component 110. Modification in operation mode On-Off for electrical optimization. Type of termination Solder Lug for connector or device. The highest AC voltage specification 125 V for the device. The highest DC voltage specification 125 V for components.
