Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 3900 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount | |
| Electrical Pathway | SPDT | |
| Switch Operation Mode | On-Off-On | |
| Ampere Capacity Rating | 16A (AC), 14A (DC) | |
| AC Voltage Max | 125 V | |
| DC Voltage Max | 36 V | |
| Activator Mechanism Type | Standard Round | |
| Activator Arm Length | 17.50mm | |
| Backlighting Feature | Non-Illuminated | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Lead Termination Type | Quick Connect - 0.250" (6.3mm) | |
| Mount Cutout Specs | Circular - 12.70mm Dia | |
| Insulator Thread Pattern | 15/32-32 | |
| Dust Water Resistance Rating | IP67 - Dust Tight, Waterproof | |
| Key Product Highlights | - | |
| Ambient Temp Range | - |
Description
Engineered with an actuator length of 17.50mm to provide sufficient interaction range. Incorporates a Standard Round actuator type to fulfill the desired function. Crafted with a bushing thread dimension of 15/32-32 to guarantee a secure connection. Configured for circuit type described as SPDT. Sets the ampere rating to 16A (AC), 14A (DC). Provides Non-Illuminated brightness for improved visibility. Rated with IP IP67 - Dust Tight, Waterproof to safeguard against dust and moisture penetration. Mounting configuration Panel Mount for structural stability. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Circular - 12.70mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component 3900. Modification in operation mode On-Off-On for electrical optimization. Type of termination Quick Connect - 0.250" (6.3mm) for connector or device. The highest AC voltage specification 125 V for the device. The highest DC voltage specification 36 V for components.
