Stock:
Distributor: 122
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 5000 | ₹ 36.47000 | ₹ 1,82,350.00 |
| 3000 | ₹ 37.80000 | ₹ 1,13,400.00 |
| 2000 | ₹ 40.99000 | ₹ 81,980.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | LPV | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Electrical Pathway | SPST-NO | |
| Switch Operation Mode | Off-Mom | |
| Pin Voltage Tolerance | 0.05A @ 12VDC | |
| Activator Mechanism Type | Standard | |
| Attachment Mounting Style | Through Hole, Right Angle | |
| Vertical Activator PCB Height | - | |
| Right-Angle Activator Length | 11.35mm | |
| Activator Alignment Direction | Side Actuated | |
| Lead Termination Type | PC Pin | |
| Dimensional Outline Drawing | 7.50mm x 7.00mm | |
| Backlighting Feature | Non-Illuminated | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Activation Pressure Required | 160gf | |
| Dust Water Resistance Rating | IP40 | |
| Key Product Highlights | Tactile Feedback | |
| Ambient Temp Range | -20°C ~ 70°C |
Description
Set up with a right-angle actuator length of 11.35mm for effective assembly. Aligned with Side Actuated actuator orientation for precise placement. Incorporates a Standard actuator type to fulfill the desired function. Configured for circuit type described as SPST-NO. Offers a contact rating at the voltage level of 0.05A @ 12VDC. Equipped with features categorized as Tactile Feedback. Provides Non-Illuminated brightness for improved visibility. Rated with IP IP40 to safeguard against dust and moisture penetration. Mounting configuration Through Hole, Right Angle for structural stability. Pressure applied 160gf for ergonomic or mechanical operations. Temperature range -20°C ~ 70°C for environmental conditions impacting thermal efficiency. Shape outline 7.50mm x 7.00mm for device design and footprint. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component LPV. Modification in operation mode Off-Mom for electrical optimization. Type of termination PC Pin for connector or device.
