Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | EDM | |
| IC Encapsulation Type | Bag | |
| Availability Status | Obsolete | |
| Electrical Pathway | SPST-NO | |
| Switch Operation Mode | Off-Mom | |
| Pin Voltage Tolerance | 0.05A @ 100VAC/DC | |
| Activator Mechanism Type | Snap Dome | |
| Attachment Mounting Style | Through Hole | |
| Vertical Activator PCB Height | 1.20mm | |
| Right-Angle Activator Length | - | |
| Activator Alignment Direction | Top Actuated | |
| Lead Termination Type | PC Pin | |
| Dimensional Outline Drawing | 11.30mm x 10.35mm | |
| Backlighting Feature | Non-Illuminated | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Activation Pressure Required | 450gf | |
| Dust Water Resistance Rating | - | |
| Key Product Highlights | Tactile Feedback | |
| Ambient Temp Range | -55°C ~ 85°C |
Description
Rises 1.20mm vertically above the PCB. Aligned with Top Actuated actuator orientation for precise placement. Incorporates a Snap Dome actuator type to fulfill the desired function. Configured for circuit type described as SPST-NO. Offers a contact rating at the voltage level of 0.05A @ 100VAC/DC. Equipped with features categorized as Tactile Feedback. Provides Non-Illuminated brightness for improved visibility. Mounting configuration Through Hole for structural stability. Pressure applied 450gf for ergonomic or mechanical operations. Temperature range -55°C ~ 85°C for environmental conditions impacting thermal efficiency. Shape outline 11.30mm x 10.35mm for device design and footprint. Type of housing Bag for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component EDM. Modification in operation mode Off-Mom for electrical optimization. Type of termination PC Pin for connector or device.
