Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 56300 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Electrical Pathway | DP3T | |
| Switch Activation Sequence | Non-Shorting (BBM) | |
| Switch Operation Mode | On-On-On | |
| Ampere Capacity Rating | 500mA (AC/DC) | |
| AC Voltage Max | 125 V | |
| DC Voltage Max | 125 V | |
| Activator Mechanism Type | Standard | |
| Activator Arm Length | 4.75mm | |
| Pin Alloy Composition | Copper Alloy | |
| Pin Surface Treatment | Silver | |
| Attachment Mounting Style | Through Hole | |
| Lead Termination Type | PC Pin | |
| Key Product Highlights | - | |
| Ambient Temp Range | -20°C ~ 70°C |
Description
Engineered with an actuator length of 4.75mm to provide sufficient interaction range. Incorporates a Standard actuator type to fulfill the desired function. Configured for circuit type described as DP3T. Includes contact finish plated at Silver to improve conductivity. Constructed from the contact material known as Copper Alloy. Displays the contact timing characteristics defined as Non-Shorting (BBM). Sets the ampere rating to 500mA (AC/DC). Mounting configuration Through Hole for structural stability. Temperature range -20°C ~ 70°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component 56300. Modification in operation mode On-On-On for electrical optimization. Type of termination PC Pin for connector or device. The highest AC voltage specification 125 V for the device. The highest DC voltage specification 125 V for components.
