Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | MR | |
| IC Encapsulation Type | BulkBulk | |
| Availability Status | Obsolete | |
| Switch Position Options | 3 | |
| Rotation Stop Positions | Fixed | |
| Switch Deck Layers | 1 | |
| Poles per Switch Layer | 2 | |
| Circuits per Layer | DPDT | |
| Switch Activation Sequence | Non-Shorting (BBM) | |
| Ampere Capacity Rating | 5A (AC), 3A (DC) | |
| AC Voltage Max | 125 V | |
| DC Voltage Max | 30 V | |
| Activator Mechanism Type | Knob | |
| Activator Arm Length | 15.80mm | |
| Switch Throw Angle | 60° | |
| Pin Alloy Composition | Silver Alloy | |
| Pin Surface Treatment | - | |
| Attachment Mounting Style | Panel Mount, Right Angle | |
| Lead Termination Type | Solder Lug | |
| Key Product Highlights | Sealed - Flux Protection | |
| Rear Panel Extension | 12.00mm |
Description
Engineered with an actuator length of 15.80mm to provide sufficient interaction range. Incorporates a Knob actuator type to fulfill the desired function. Delivers a throw angle of 60° for efficient switching operation. Features DPDT circuits per layer in systems with multiple controls. Constructed from the contact material known as Silver Alloy. Displays the contact timing characteristics defined as Non-Shorting (BBM). Sets the ampere rating to 5A (AC), 3A (DC). Details the depth behind the panel noted at 12.00mm. Equipped with features categorized as Sealed - Flux Protection. Equipped with Fixed index stops for precise positioning. Mounting configuration Panel Mount, Right Angle for structural stability. Total decks 1 used in mechanical or card-based systems. Number of poles per layer 2 for multi-layer switches or circuits. Overall number of positions 3 for switches or mechanical components. Type of housing BulkBulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component MR. Type of termination Solder Lug for connector or device. The highest AC voltage specification 125 V for the device. The highest DC voltage specification 30 V for components.
