Stock:
Distributor: 111
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 7 | ₹ 1,119.64000 | ₹ 7,837.48 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | MSS | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount, Front | |
| Device Type Classification | Anti-Vandal | |
| Electrical Pathway | SPST | |
| Switch Operation Mode | On-Off | |
| Ampere Capacity Rating | 100mA (DC) | |
| AC Voltage Max | - | |
| DC Voltage Max | 60 V | |
| Activator Mechanism Type | Round, Button, Flush | |
| Activator Label Indicator | - | |
| Activator Cap Shade | Silver | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Lead Termination Type | Wire Leads | |
| Dust Water Resistance Rating | IP67 - Dust Tight, Waterproof | |
| Key Product Highlights | - | |
| Mount Cutout Specs | Circular - 22.00mm Dia | |
| Ambient Temp Range | -40°C ~ 85°C |
Description
Incorporates a Round, Button, Flush actuator type to fulfill the desired function. Configured for circuit type described as SPST. Made with an actuator or cap color labeled as Silver for visual differentiation. Sets the ampere rating to 100mA (DC). Rated with IP IP67 - Dust Tight, Waterproof to safeguard against dust and moisture penetration. Mounting configuration Panel Mount, Front for structural stability. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Specifications of the cutout Circular - 22.00mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component MSS. Modification in operation mode On-Off for electrical optimization. Type of termination Wire Leads for connector or device. Type classification Anti-Vandal for specifications. The highest DC voltage specification 60 V for components.
