Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | PSE HI 22 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Attachment Mounting Style | Panel Mount, Front | |
| Device Type Classification | Piezo, Anti-Vandal | |
| Electrical Pathway | SPST-NO | |
| Switch Operation Mode | Off-Mom | |
| Ampere Capacity Rating | 100mA (AC/DC) | |
| AC Voltage Max | 42 V | |
| DC Voltage Max | 60 V | |
| Activator Mechanism Type | Round, Button, Flush | |
| Activator Label Indicator | No Marking | |
| Activator Cap Shade | Green | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Lead Termination Type | Wire Leads | |
| Dust Water Resistance Rating | IP67 - Dust Tight, Waterproof | |
| Key Product Highlights | - | |
| Mount Cutout Specs | Circular - 22.10mm Dia | |
| Ambient Temp Range | -20°C ~ 60°C |
Description
Features labels marked as No Marking for easy identification. Incorporates a Round, Button, Flush actuator type to fulfill the desired function. Configured for circuit type described as SPST-NO. Made with an actuator or cap color labeled as Green for visual differentiation. Sets the ampere rating to 100mA (AC/DC). Rated with IP IP67 - Dust Tight, Waterproof to safeguard against dust and moisture penetration. Mounting configuration Panel Mount, Front for structural stability. Temperature range -20°C ~ 60°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Circular - 22.10mm Dia for accurate mounting. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component PSE HI 22. Modification in operation mode Off-Mom for electrical optimization. Type of termination Wire Leads for connector or device. Type classification Piezo, Anti-Vandal for specifications. The highest AC voltage specification 42 V for the device. The highest DC voltage specification 60 V for components.
