Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | MPI | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount, Front | |
| Device Type Classification | Anti-Vandal, Illuminated | |
| Electrical Pathway | SPST-NO | |
| Switch Operation Mode | Off-Mom | |
| Ampere Capacity Rating | 50mA (DC) | |
| AC Voltage Max | - | |
| DC Voltage Max | 24 V | |
| Activator Mechanism Type | Round, Button, Flush | |
| Activator Label Indicator | - | |
| Activator Cap Shade | Silver | |
| LED Illumination Shades | LED, Blue | |
| Standard Illumination Volts | 3.5 VDC | |
| Lead Termination Type | Screw Terminal | |
| Dust Water Resistance Rating | IP66 - Dust Tight, Water Resistant | |
| Key Product Highlights | - | |
| Mount Cutout Specs | Circular - 19.20mm Dia | |
| Ambient Temp Range | -30°C ~ 70°C |
Description
Incorporates a Round, Button, Flush actuator type to fulfill the desired function. Configured for circuit type described as SPST-NO. Made with an actuator or cap color labeled as Silver for visual differentiation. Sets the ampere rating to 50mA (DC). Includes LED, Blue colored LEDs for effective signaling. Works at a standard voltage of 3.5 VDC for illumination. Rated with IP IP66 - Dust Tight, Water Resistant to safeguard against dust and moisture penetration. Mounting configuration Panel Mount, Front for structural stability. Temperature range -30°C ~ 70°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Circular - 19.20mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component MPI. Modification in operation mode Off-Mom for electrical optimization. Type of termination Screw Terminal for connector or device. Type classification Anti-Vandal, Illuminated for specifications. The highest DC voltage specification 24 V for components.
