Stock:
Distributor: 122
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 240 | ₹ 2,475.09000 | ₹ 5,94,021.60 |
| 80 | ₹ 2,585.45000 | ₹ 2,06,836.00 |
| 50 | ₹ 2,659.32000 | ₹ 1,32,966.00 |
| 25 | ₹ 2,774.13000 | ₹ 69,353.25 |
| 10 | ₹ 2,877.37000 | ₹ 28,773.70 |
| 1 | ₹ 3,140.81000 | ₹ 3,140.81 |
Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 2,855.12000 | ₹ 2,855.12 |
| 10 | ₹ 2,526.71000 | ₹ 25,267.10 |
| 25 | ₹ 2,503.57000 | ₹ 62,589.25 |
| 50 | ₹ 2,330.02000 | ₹ 1,16,501.00 |
Stock:
Distributor: 111
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 10 | ₹ 3,265.80000 | ₹ 32,658.00 |
| 6 | ₹ 3,379.53000 | ₹ 20,277.18 |
| 2 | ₹ 3,860.54000 | ₹ 7,721.08 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Panel Mount, Front | |
| Device Type Classification | Standard, Illuminated | |
| Electrical Pathway | DPDT | |
| Switch Operation Mode | On-On | |
| Ampere Capacity Rating | 3A (AC) | |
| AC Voltage Max | 250 V | |
| DC Voltage Max | - | |
| Activator Mechanism Type | Round, Button, Flush | |
| Activator Label Indicator | No Marking | |
| Activator Cap Shade | Silver | |
| LED Illumination Shades | LED, Red | |
| Standard Illumination Volts | 12 VDC | |
| Lead Termination Type | Solder Lug | |
| Dust Water Resistance Rating | IP40 | |
| Key Product Highlights | Stainless Steel | |
| Mount Cutout Specs | Circular - 16.20mm Dia | |
| Ambient Temp Range | -20°C ~ 55°C |
Description
Features labels marked as No Marking for easy identification. Incorporates a Round, Button, Flush actuator type to fulfill the desired function. Configured for circuit type described as DPDT. Made with an actuator or cap color labeled as Silver for visual differentiation. Sets the ampere rating to 3A (AC). Equipped with features categorized as Stainless Steel. Includes LED, Red colored LEDs for effective signaling. Works at a standard voltage of 12 VDC for illumination. Rated with IP IP40 to safeguard against dust and moisture penetration. Mounting configuration Panel Mount, Front for structural stability. Temperature range -20°C ~ 55°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Specifications of the cutout Circular - 16.20mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Modification in operation mode On-On for electrical optimization. Type of termination Solder Lug for connector or device. Type classification Standard, Illuminated for specifications. The highest AC voltage specification 250 V for the device.
