Stock:
Distributor: 118
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 4 | ₹ 25,617.39000 | ₹ 1,02,469.56 |
| 1 | ₹ 26,370.84000 | ₹ 26,370.84 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | GLS | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Electrical Pathway | DPST-NC (DB) | |
| Switch Operation Mode | On-Mom | |
| Ampere Capacity Rating | 6A (AC), 550mA (DC) | |
| AC Voltage Max | 120 V | |
| DC Voltage Max | 125 V | |
| Activator Mechanism Type | Side Rotary, Adjustable Roller | |
| Attachment Mounting Style | Chassis Mount | |
| Lead Termination Type | Screw Terminal | |
| Dust Water Resistance Rating | IP67 - Dust Tight, Waterproof | |
| Key Product Highlights | - | |
| Activation Pressure Required | 33gfm | |
| Detachment Pressure | - | |
| Functional Position Setting | 26° | |
| Initial Travel Distance | 26° | |
| Switch Travel Difference | 12° | |
| Excess Travel Distance | 59° | |
| Physical Durability Cycles | 15,000,000 Cycles | |
| Cycle Durability Rating | - | |
| Ambient Temp Range | -25°C ~ 85°C |
Description
Incorporates a Side Rotary, Adjustable Roller actuator type to fulfill the desired function. Configured for circuit type described as DPST-NC (DB). Sets the ampere rating to 6A (AC), 550mA (DC). Offers a measurement of the differential travel at 12°. Rated with IP IP67 - Dust Tight, Waterproof to safeguard against dust and moisture penetration. Mechanical strength 15,000,000 Cycles cycles for durability. Mounting configuration Chassis Mount for structural stability. Pressure applied 33gfm for ergonomic or mechanical operations. Position configuration 26° for correct device alignment. Temperature range -25°C ~ 85°C for environmental conditions impacting thermal efficiency. Additional travel distance 59° for mechanical safety and longevity. Type of housing Bulk for safeguarding or transporting components. Initial distance 26° for mechanical control or switch activation. Product status Active concerning availability and lifecycle. Classification series for the product or component GLS. Modification in operation mode On-Mom for electrical optimization. Type of termination Screw Terminal for connector or device. The highest AC voltage specification 120 V for the device. The highest DC voltage specification 125 V for components.
