Stock:
Distributor: 118
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 5 | ₹ 20,887.87000 | ₹ 1,04,439.35 |
| 1 | ₹ 21,502.22000 | ₹ 21,502.22 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 914CE | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Electrical Pathway | SPDT | |
| Switch Operation Mode | On-Mom | |
| Ampere Capacity Rating | 5A (AC), 3A (DC) | |
| AC Voltage Max | 240 V | |
| DC Voltage Max | 28 V | |
| Activator Mechanism Type | Spring, Wire | |
| Attachment Mounting Style | Chassis Mount | |
| Lead Termination Type | Cable Leads | |
| Dust Water Resistance Rating | IP66 - Dust Tight, Water Resistant | |
| Key Product Highlights | - | |
| Activation Pressure Required | 56gf | |
| Detachment Pressure | - | |
| Functional Position Setting | 1.100" (28.0mm) | |
| Initial Travel Distance | - | |
| Switch Travel Difference | - | |
| Excess Travel Distance | - | |
| Physical Durability Cycles | 10,000,000 Cycles | |
| Cycle Durability Rating | - | |
| Ambient Temp Range | 0°C ~ 105°C |
Description
Incorporates a Spring, Wire actuator type to fulfill the desired function. Configured for circuit type described as SPDT. Sets the ampere rating to 5A (AC), 3A (DC). Rated with IP IP66 - Dust Tight, Water Resistant to safeguard against dust and moisture penetration. Mechanical strength 10,000,000 Cycles cycles for durability. Mounting configuration Chassis Mount for structural stability. Pressure applied 56gf for ergonomic or mechanical operations. Position configuration 1.100" (28.0mm) for correct device alignment. Temperature range 0°C ~ 105°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component 914CE. Modification in operation mode On-Mom for electrical optimization. Type of termination Cable Leads for connector or device. The highest AC voltage specification 240 V for the device. The highest DC voltage specification 28 V for components.
