Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | MDS | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Electrical Pathway | SPDT | |
| Switch Operation Mode | On-Mom | |
| Ampere Capacity Rating | 300mA (DC) | |
| AC Voltage Max | - | |
| DC Voltage Max | 30 V | |
| Activator Mechanism Type | Lever, Straight | |
| Attachment Mounting Style | Through Hole | |
| Lead Termination Type | PC Pin | |
| Dust Water Resistance Rating | - | |
| Key Product Highlights | - | |
| Activation Pressure Required | 50gf | |
| Detachment Pressure | 3.000gf | |
| Functional Position Setting | - | |
| Initial Travel Distance | - | |
| Switch Travel Difference | - | |
| Excess Travel Distance | - | |
| Physical Durability Cycles | 30,000 Cycles | |
| Cycle Durability Rating | 30,000 Cycles | |
| Ambient Temp Range | -10°C ~ 60°C |
Description
Incorporates a Lever, Straight actuator type to fulfill the desired function. Configured for circuit type described as SPDT. Sets the ampere rating to 300mA (DC). Indicates electrical lifespan evaluated at 30,000 Cycles. Mechanical strength 30,000 Cycles cycles for durability. Mounting configuration Through Hole for structural stability. Pressure applied 50gf for ergonomic or mechanical operations. Temperature range -10°C ~ 60°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Force needed 3.000gf to activate mechanical or electrical switches. Classification series for the product or component MDS. Modification in operation mode On-Mom for electrical optimization. Type of termination PC Pin for connector or device. The highest DC voltage specification 30 V for components.
