Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | M6 | |
| IC Encapsulation Type | Retail Package | |
| Availability Status | Active | |
| Electrical Pathway | SPDT | |
| Switch Position Options | 2 | |
| Switch Operation Mode | On-On | |
| Switch Activation Sequence | - | |
| Ampere Capacity Rating | 2A (AC), 400mA (DC) | |
| AC Voltage Max | 250 V | |
| DC Voltage Max | 125 V | |
| Activator Mechanism Type | Flat Key | |
| Key Extraction Slots | All | |
| Switch Throw Angle | 90° | |
| Pin Alloy Composition | Silver (Ag) | |
| Pin Surface Treatment | Palladium | |
| Attachment Mounting Style | Panel Mount | |
| Lead Termination Type | Quick Connect - 0.110" (2.8mm) | |
| Mount Cutout Specs | Circular - 16.20mm Dia | |
| Key Product Highlights | UL94 V-0, IP65 | |
| Ambient Temp Range | -25°C ~ 55°C |
Description
Incorporates a Flat Key actuator type to fulfill the desired function. Delivers a throw angle of 90° for efficient switching operation. Configured for circuit type described as SPDT. Includes contact finish plated at Palladium to improve conductivity. Constructed from the contact material known as Silver (Ag). Sets the ampere rating to 2A (AC), 400mA (DC). Equipped with features categorized as UL94 V-0, IP65. Supports All removable key locations for flexible operation. Mounting configuration Panel Mount for structural stability. Overall number of positions 2 for switches or mechanical components. Temperature range -25°C ~ 55°C for environmental conditions impacting thermal efficiency. Type of housing Retail Package for safeguarding or transporting components. Specifications of the cutout Circular - 16.20mm Dia for accurate mounting. Product status Active concerning availability and lifecycle. Classification series for the product or component M6. Modification in operation mode On-On for electrical optimization. Type of termination Quick Connect - 0.110" (2.8mm) for connector or device. The highest AC voltage specification 250 V for the device. The highest DC voltage specification 125 V for components.
