Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | GL | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Proximity Detection Range | 0.124" (3.15mm) | |
| Detection Technology Type | Optical Flag | |
| Output Setup Options | NPN | |
| Max Forward DC Current | 50 mA | |
| Maximum Collector Amps | 20 mA | |
| Max Collector-Emitter Breakdown | 30 V | |
| Activation Speed ms | 25µs | |
| Ambient Temp Range | -20°C ~ 85°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | Module, Wire Leads |
Description
Has a peak collector current (Ic) of 20 mA. Offers a maximum DC forward current (If) specified at 50 mA. Mounting configuration Chassis Mount for structural stability. Temperature range -20°C ~ 85°C for environmental conditions impacting thermal efficiency. Preferences NPN for establishing system output configurations. Type of housing Box for safeguarding or transporting components. Style of the enclosure/case Module, Wire Leads that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Time taken to respond 25µs for rapid operation or detection. Sensor detection range 0.124" (3.15mm) for sensors or detectors. Method of detection Optical Flag for device operation. Classification series for the product or component GL. Maximum collector-emitter breakdown voltage 30 V.
