Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | MPX4115A | |
| IC Encapsulation Type | Tray | |
| Availability Status | Obsolete | |
| Intended Uses | Board Mount | |
| Pressure Sensing Mode | Absolute | |
| Working Pressure Limit | 2.18PSI ~ 16.68PSI (15kPa ~ 115kPa) | |
| Exit Signal Category | Analog Voltage | |
| Signal Output Format | 0.2 V ~ 4.8 V | |
| Precision Level | - | |
| Power Supply Voltage | 4.85V ~ 5.35V | |
| Network Port Dimension | Male - 0.19" (4.93mm) Tube | |
| Interface Port Design | Barbed | |
| Key Product Highlights | Temperature Compensated | |
| Lead Termination Type | PC Pin | |
| Peak Pressure Tolerance | 58.02PSI (400kPa) | |
| Ambient Temp Range | -40°C ~ 125°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 6-SIP Module | |
| Vendor Package Type | - |
Description
Perfectly designed for situations involving Board Mount. Equipped with features categorized as Temperature Compensated. Maximum pressure 58.02PSI (400kPa) for hydraulic or pneumatic applications. Mounting configuration Through Hole for structural stability. Maximum pressure threshold 2.18PSI ~ 16.68PSI (15kPa ~ 115kPa) for pneumatic or hydraulic operations. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Output format 0.2 V ~ 4.8 V for electrical or signal communication. Type Analog Voltage for ensuring compatibility with output systems. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case 6-SIP Module that offers mechanical and thermal protection. The Male - 0.19" (4.93mm) Tube measurement of the port for mechanical or fluid compatibility. The Barbed configuration of the port for connector or interface categorization. Category of pressure Absolute for operational or measurement purposes. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component MPX4115A. Voltage requirement 4.85V ~ 5.35V for electrical specifications. Type of termination PC Pin for connector or device. Voltage supply 4.85V ~ 5.35V for device operation.
