Stock:
Distributor: 118
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 18 | ₹ 1,215.99000 | ₹ 21,887.82 |
| 6 | ₹ 1,314.58000 | ₹ 7,887.48 |
| 1 | ₹ 1,478.90000 | ₹ 1,478.90 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | TBP | |
| IC Encapsulation Type | Tube | |
| Availability Status | Active | |
| Intended Uses | Board Mount | |
| Pressure Sensing Mode | Vented Gauge | |
| Working Pressure Limit | 100PSI (689.48kPa) | |
| Exit Signal Category | Wheatstone Bridge | |
| Signal Output Format | 0 mV ~ 25.5 mV (5V) | |
| Precision Level | ±0.15% | |
| Power Supply Voltage | 1.5V ~ 12V | |
| Network Port Dimension | Male - 0.11" (2.74mm) Tube | |
| Interface Port Design | Barbed | |
| Key Product Highlights | Temperature Compensated | |
| Lead Termination Type | SMD (SMT) Tab | |
| Peak Pressure Tolerance | 245PSI (1689.22kPa) | |
| Ambient Temp Range | -40°C ~ 125°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 6-SMD, No Lead, Top Port | |
| Vendor Package Type | 6-SMT |
Description
Delivers measurement precision rated at ±0.15% for reliable results. Perfectly designed for situations involving Board Mount. Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Equipped with features categorized as Temperature Compensated. Maximum pressure 245PSI (1689.22kPa) for hydraulic or pneumatic applications. Mounting configuration Surface Mount for structural stability. Maximum pressure threshold 100PSI (689.48kPa) for pneumatic or hydraulic operations. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Output format 0 mV ~ 25.5 mV (5V) for electrical or signal communication. Type Wheatstone Bridge for ensuring compatibility with output systems. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 6-SMD, No Lead, Top Port that offers mechanical and thermal protection. Type of package 6-SMT that preserves the integrity of the device. The Male - 0.11" (2.74mm) Tube measurement of the port for mechanical or fluid compatibility. The Barbed configuration of the port for connector or interface categorization. Category of pressure Vented Gauge for operational or measurement purposes. Product status Active concerning availability and lifecycle. Classification series for the product or component TBP. Supplier package type 6-SMT for component selection. Voltage requirement 1.5V ~ 12V for electrical specifications. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Type of termination SMD (SMT) Tab for connector or device. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. Voltage supply 1.5V ~ 12V for device operation.
