Stock:
Distributor: 118
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 17 | ₹ 2,696.52000 | ₹ 45,840.84 |
| 8 | ₹ 2,846.33000 | ₹ 22,770.64 |
| 1 | ₹ 2,996.13000 | ₹ 2,996.13 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | ABP | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Intended Uses | Medical Ventilation | |
| Pressure Sensing Mode | Vented Gauge | |
| Working Pressure Limit | 8.7PSI (60kPa) | |
| Exit Signal Category | Analog Voltage | |
| Signal Output Format | 0.33 V ~ 2.97 V | |
| Precision Level | ±0.25% | |
| Power Supply Voltage | 3.3V | |
| Network Port Dimension | Male - 0.11" (2.67mm) Tube | |
| Interface Port Design | Barbless | |
| Key Product Highlights | Amplified Output, Temperature Compensated | |
| Lead Termination Type | SMD (SMT) Tab | |
| Peak Pressure Tolerance | 29.01PSI (200kPa) | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 6-SMD Module, No Lead | |
| Vendor Package Type | Module |
Description
Delivers measurement precision rated at ±0.25% for reliable results. Perfectly designed for situations involving Medical Ventilation. Equipped with features categorized as Amplified Output, Temperature Compensated. Maximum pressure 29.01PSI (200kPa) for hydraulic or pneumatic applications. Mounting configuration Surface Mount for structural stability. Maximum pressure threshold 8.7PSI (60kPa) for pneumatic or hydraulic operations. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Output format 0.33 V ~ 2.97 V for electrical or signal communication. Type Analog Voltage for ensuring compatibility with output systems. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case 6-SMD Module, No Lead that offers mechanical and thermal protection. Type of package Module that preserves the integrity of the device. The Male - 0.11" (2.67mm) Tube measurement of the port for mechanical or fluid compatibility. The Barbless configuration of the port for connector or interface categorization. Category of pressure Vented Gauge for operational or measurement purposes. Product status Active concerning availability and lifecycle. Classification series for the product or component ABP. Supplier package type Module for component selection. Voltage requirement 3.3V for electrical specifications. Type of termination SMD (SMT) Tab for connector or device. Voltage supply 3.3V for device operation.
