Stock:
Distributor: 118
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 4 | ₹ 1,28,160.00000 | ₹ 5,12,640.00 |
| 3 | ₹ 1,36,704.00000 | ₹ 4,10,112.00 |
| 1 | ₹ 1,49,520.00000 | ₹ 1,49,520.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | 140PC | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Intended Uses | Board Mount | |
| Pressure Sensing Mode | Vented Gauge | |
| Working Pressure Limit | 1PSI (6.89kPa) | |
| Exit Signal Category | Analog Voltage | |
| Signal Output Format | 1 V ~ 6 V | |
| Precision Level | ±0.75% | |
| Power Supply Voltage | 7V ~ 16V | |
| Network Port Dimension | Male - 0.2" (5mm) Tube | |
| Interface Port Design | Barbless | |
| Key Product Highlights | Amplified Output, Temperature Compensated | |
| Lead Termination Type | PC Pin | |
| Peak Pressure Tolerance | 20PSI (137.9kPa) | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 3-SIP Module | |
| Vendor Package Type | - |
Description
Delivers measurement precision rated at ±0.75% for reliable results. Perfectly designed for situations involving Board Mount. Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Equipped with features categorized as Amplified Output, Temperature Compensated. Maximum pressure 20PSI (137.9kPa) for hydraulic or pneumatic applications. Mounting configuration Through Hole for structural stability. Maximum pressure threshold 1PSI (6.89kPa) for pneumatic or hydraulic operations. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Output format 1 V ~ 6 V for electrical or signal communication. Type Analog Voltage for ensuring compatibility with output systems. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case 3-SIP Module that offers mechanical and thermal protection. The Male - 0.2" (5mm) Tube measurement of the port for mechanical or fluid compatibility. The Barbless configuration of the port for connector or interface categorization. Category of pressure Vented Gauge for operational or measurement purposes. Product status Active concerning availability and lifecycle. Classification series for the product or component 140PC. Voltage requirement 7V ~ 16V for electrical specifications. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Type of termination PC Pin for connector or device. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. Voltage supply 7V ~ 16V for device operation.
