Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 6909 | |
| IC Encapsulation Type | Bag | |
| Availability Status | Obsolete | |
| Measurement Target Type | Rotary Position | |
| Core Technology Platform | Resistive | |
| Electrical Mechanical Turn Angle | 0° ~ 340°, Continuous | |
| Proportional Response Range | - | |
| Signal Output Format | Resistive | |
| Processed Signal Type | Clockwise Increase | |
| Activator Mechanism Type | Exposed Element - Rotary | |
| Response Curve Straightness | ±0.5% | |
| Ohm Resistance Value | 5 kOhms | |
| Ohm Accuracy Percentage | ±10% | |
| Power Supply Voltage | - | |
| Attachment Mounting Style | Custom | |
| Lead Termination Type | Wire Leads | |
| Ambient Temp Range | -65°C ~ 125°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Component Housing Style | Ring, Wire Leads | |
| Vendor Package Type | - |
Description
Incorporates a Exposed Element - Rotary actuator type to fulfill the desired function. Intended for measurement purposes classified as Rotary Position. Ensures ±0.5% linearity for precise signal responses. Mounting configuration Custom for structural stability. Temperature range -65°C ~ 125°C for environmental conditions impacting thermal efficiency. Output format Resistive for electrical or signal communication. Category Clockwise Increase for transmitting communication or control output signals. Type of housing Bag for safeguarding or transporting components. Style of the enclosure/case Ring, Wire Leads that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Resistance value 5 kOhms for electrical performance. The permissible variation for resistance ±10% to comply with regulatory requirements. The rotation angle for electrical/mechanical 0° ~ 340°, Continuous to ensure proper device operation. Classification series for the product or component 6909. The primary technology platform Resistive linked to the product category. Type of termination Wire Leads for connector or device.
