Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Light Wavelength nm | 950nm | |
| Vivid Color Option | - | |
| Light Spectrum Coverage | 800nm ~ 1100nm | |
| Semiconductor Diode Category | PIN | |
| Sensitivity at Wavelength | - | |
| Activation Speed ms | 20ns | |
| Max Reverse DC Voltage | 32 V | |
| Typical Dark Current | 2nA | |
| Functional Surface Area | 7.02mm² | |
| Display View Cone Degrees | 120° | |
| Ambient Temp Range | -40°C ~ 100°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Radial |
Description
Features an active display area of 7.02mm² for improved visibility. Shows a typical dark current recorded at 2nA. Shows the type of diode identified as PIN. Mounting configuration Through Hole for structural stability. Temperature range -40°C ~ 100°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Radial that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Time taken to respond 20ns for rapid operation or detection. Wavelength range 800nm ~ 1100nm for illumination or sensor applications. Viewing angle 120° for monitors. Maximum reverse DC voltage 32 V for diode applications. Wavelength of light 950nm for RF or optical devices.
