Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | HEDS | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Position Encoder Category | Optical | |
| Exit Signal Category | Quadrature with Index (Incremental) | |
| Encoder Pulse Count per Turn | 500 | |
| Power Supply Voltage | 5V | |
| Activator Mechanism Type | 3mm Open Center | |
| Notch Position Hold | No | |
| Integrated Toggle Control | No | |
| Attachment Mounting Style | Chassis Mount, Motors | |
| Installation Orientation | Vertical | |
| Lead Termination Type | Terminal Pins | |
| Minimum Rotation Cycles | - | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Incorporates a 3mm Open Center actuator type to fulfill the desired function. Includes a built-in toggle system categorized as No. Incorporates a detent mechanism rated at No. Refers to the category of features recognized by the encoder as Optical. Mounting configuration Chassis Mount, Motors for structural stability. Alignment Vertical for proper installation or signal positioning. Type Quadrature with Index (Incremental) for ensuring compatibility with output systems. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Number of pulses per revolution 500 for rotary encoders or motors. Classification series for the product or component HEDS. Voltage requirement 5V for electrical specifications. Type of termination Terminal Pins for connector or device. Voltage supply 5V for device operation.
