Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | CERALOCK® CSTNE | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Device Type Classification | Ceramic | |
| Oscillation Rate Hz | 16 MHz | |
| Oscillator Drift Tolerance | ±0.3% | |
| Hz Deviation Limit | ±0.5% | |
| Key Product Highlights | Built in Capacitor | |
| Storage Capacity Electrical | 5 pF | |
| AC Resistance Value | 40 Ohms | |
| Ambient Temp Range | -40°C ~ 125°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 3-SMD, Non-Standard | |
| Package Size Specs | 0.126" L x 0.051" W (3.20mm x 1.30mm) | |
| Vertical Dimension | 0.039" (1.00mm) |
Description
Provides a capacitance level rated at 5 pF to maintain circuit stability. Equipped with features categorized as Built in Capacitor. Runs at a frequency of 16 MHz. Offers ±0.3% frequency consistency under various environmental conditions. Provides ±0.5% frequency range for accurate electronic operations. Features a height of 0.039" (1.00mm) for accurate dimensional precision. Configured with 40 Ohms impedance to maintain signal quality. Mounting configuration Surface Mount for structural stability. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 3-SMD, Non-Standard that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component CERALOCK® CSTNE. Details on package size 0.126" L x 0.051" W (3.20mm x 1.30mm) for electrical or mechanical components. Measurement dimensions 0.126" L x 0.051" W (3.20mm x 1.30mm) for component specifications. Type classification Ceramic for specifications.
