Stock:
Distributor: 140
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 100 | ₹ 3,284.10000 | ₹ 3,28,410.00 |
| 50 | ₹ 3,551.10000 | ₹ 1,77,555.00 |
| 25 | ₹ 3,818.10000 | ₹ 95,452.50 |
| 1 | ₹ 8,010.00000 | ₹ 8,010.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | OX-221 | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT) | |
| Availability Status | Active | |
| Fundamental Oscillator | Crystal | |
| Device Type Classification | OCXO | |
| Oscillation Rate Hz | 20 MHz | |
| Primary Function Mode | - | |
| Signal Output Format | LVCMOS | |
| Power Supply Voltage | 3.3V | |
| Oscillator Drift Tolerance | ±5ppb | |
| Full Pull Frequency Range | - | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Frequency Spread Range | - | |
| Maximum Supply Current | 700mA | |
| Performance Rating Specs | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 7-SMD, No Lead | |
| Vendor Package Type | - | |
| Package Size Specs | 1.000" L x 0.866" W (25.40mm x 22.00mm) | |
| Maximum Mounted Height | 0.486" (12.35mm) |
Description
Incorporates a Crystal base resonator to maintain stable frequency control. Manages the maximum supply current noted as 700mA. Runs at a frequency of 20 MHz. Offers ±5ppb frequency consistency under various environmental conditions. Maximum installed height of 0.486" (12.35mm) for components affixed to the board. Mounting configuration Surface Mount for structural stability. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Output format LVCMOS for electrical or signal communication. Type of housing Tape & Reel (TR)Cut Tape (CT) for safeguarding or transporting components. Style of the enclosure/case 7-SMD, No Lead that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component OX-221. Details on package size 1.000" L x 0.866" W (25.40mm x 22.00mm) for electrical or mechanical components. Measurement dimensions 1.000" L x 0.866" W (25.40mm x 22.00mm) for component specifications. Voltage requirement 3.3V for electrical specifications. Type classification OCXO for specifications. Voltage supply 3.3V for device operation.
