Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | KC7050P-L3 | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Fundamental Oscillator | Crystal | |
| Device Type Classification | XO (Standard) | |
| Oscillation Rate Hz | 100 MHz | |
| Primary Function Mode | Standby (Power Down) | |
| Signal Output Format | LVDS | |
| Power Supply Voltage | 3.3V | |
| Oscillator Drift Tolerance | ±50ppm | |
| Full Pull Frequency Range | - | |
| Ambient Temp Range | 0°C ~ 70°C | |
| Frequency Spread Range | - | |
| Maximum Supply Current | 70mA | |
| Performance Rating Specs | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 6-SMD, No Lead | |
| Vendor Package Type | - | |
| Package Size Specs | 0.276" L x 0.197" W (7.00mm x 5.00mm) | |
| Maximum Mounted Height | 0.071" (1.80mm) |
Description
Incorporates a Crystal base resonator to maintain stable frequency control. Manages the maximum supply current noted as 70mA. Runs at a frequency of 100 MHz. Offers ±50ppm frequency consistency under various environmental conditions. Engineered with Standby (Power Down) features for versatile component usage. Maximum installed height of 0.071" (1.80mm) for components affixed to the board. Mounting configuration Surface Mount for structural stability. Temperature range 0°C ~ 70°C for environmental conditions impacting thermal efficiency. Output format LVDS for electrical or signal communication. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 6-SMD, No Lead that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component KC7050P-L3. Details on package size 0.276" L x 0.197" W (7.00mm x 5.00mm) for electrical or mechanical components. Measurement dimensions 0.276" L x 0.197" W (7.00mm x 5.00mm) for component specifications. Voltage requirement 3.3V for electrical specifications. Type classification XO (Standard) for specifications. Voltage supply 3.3V for device operation.
