Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | ASTXR | |
| IC Encapsulation Type | Strip | |
| Availability Status | Obsolete | |
| Fundamental Oscillator | Crystal | |
| Device Type Classification | TCXO | |
| Oscillation Rate Hz | 26 MHz | |
| Primary Function Mode | - | |
| Signal Output Format | Clipped Sine Wave | |
| Power Supply Voltage | 1.8V | |
| Oscillator Drift Tolerance | ±500ppb | |
| Full Pull Frequency Range | - | |
| Ambient Temp Range | -30°C ~ 85°C | |
| Frequency Spread Range | - | |
| Maximum Supply Current | 1.5mA | |
| Performance Rating Specs | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 6-SMD, No Lead | |
| Vendor Package Type | 6-SMD (2.5x2) | |
| Package Size Specs | 0.098" L x 0.079" W (2.50mm x 2.00mm) | |
| Maximum Mounted Height | 0.035" (0.90mm) |
Description
Incorporates a Crystal base resonator to maintain stable frequency control. Manages the maximum supply current noted as 1.5mA. Runs at a frequency of 26 MHz. Offers ±500ppb frequency consistency under various environmental conditions. Maximum installed height of 0.035" (0.90mm) for components affixed to the board. Mounting configuration Surface Mount for structural stability. Temperature range -30°C ~ 85°C for environmental conditions impacting thermal efficiency. Output format Clipped Sine Wave for electrical or signal communication. Type of housing Strip for safeguarding or transporting components. Style of the enclosure/case 6-SMD, No Lead that offers mechanical and thermal protection. Type of package 6-SMD (2.5x2) that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component ASTXR. Details on package size 0.098" L x 0.079" W (2.50mm x 2.00mm) for electrical or mechanical components. Measurement dimensions 0.098" L x 0.079" W (2.50mm x 2.00mm) for component specifications. Supplier package type 6-SMD (2.5x2) for component selection. Voltage requirement 1.8V for electrical specifications. Type classification TCXO for specifications. Voltage supply 1.8V for device operation.
