Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | ASGTX | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Fundamental Oscillator | Crystal | |
| Device Type Classification | VCTCXO | |
| Oscillation Rate Hz | 32.768 MHz | |
| Primary Function Mode | - | |
| Signal Output Format | LVCMOS | |
| Power Supply Voltage | 3.135V ~ 3.465V | |
| Oscillator Drift Tolerance | ±1ppm | |
| Full Pull Frequency Range | - | |
| Ambient Temp Range | -30°C ~ 70°C | |
| Frequency Spread Range | - | |
| Maximum Supply Current | 45mA | |
| Performance Rating Specs | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 6-SMD, No Lead | |
| Vendor Package Type | - | |
| Package Size Specs | 0.354" L x 0.276" W (9.00mm x 7.00mm) | |
| Maximum Mounted Height | 0.088" (2.24mm) |
Description
Incorporates a Crystal base resonator to maintain stable frequency control. Manages the maximum supply current noted as 45mA. Runs at a frequency of 32.768 MHz. Offers ±1ppm frequency consistency under various environmental conditions. Maximum installed height of 0.088" (2.24mm) for components affixed to the board. Mounting configuration Surface Mount for structural stability. Temperature range -30°C ~ 70°C for environmental conditions impacting thermal efficiency. Output format LVCMOS for electrical or signal communication. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 6-SMD, No Lead that offers mechanical and thermal protection. Classification series for the product or component ASGTX. Details on package size 0.354" L x 0.276" W (9.00mm x 7.00mm) for electrical or mechanical components. Measurement dimensions 0.354" L x 0.276" W (9.00mm x 7.00mm) for component specifications. Voltage requirement 3.135V ~ 3.465V for electrical specifications. Type classification VCTCXO for specifications. Voltage supply 3.135V ~ 3.465V for device operation.
