Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Interface Connector Category | DIP to DIP | |
| Switch Position Options | 40 | |
| Grid Row Count | 2 | |
| Plug Pin Spacing | 0.100" (2.54mm) | |
| Cable Wire Pitch | 0.050" (1.27mm) | |
| Linear Length Dimension | 0.500' (152.40mm, 6.00") | |
| Key Product Highlights | - | |
| Visual Hue | Gray, Ribbon | |
| Electromagnetic Interference Protection | Unshielded | |
| Intended Usage Scenario | Socket (0.6"), Board In | |
| Wire End Connection | IDC | |
| Pin Surface Treatment | Gold | |
| Pin Coating Depth | 30.0µin (0.76µm) |
Description
Employs a cable termination method known as IDC. Offered in a shade referred to as Gray, Ribbon to enhance the system's aesthetics. Features a connector type acknowledged as DIP to DIP. Includes contact finish plated at Gold to improve conductivity. Represents the thickness of the contact finish recorded at 30.0µin (0.76µm). Overall length 0.500' (152.40mm, 6.00") for size indication. Overall number of positions 40 for switches or mechanical components. Overall rows 2 for setting up matrices or displays. Type of housing Bulk for safeguarding or transporting components. Spacing between cables 0.050" (1.27mm) for conductor arrangement. The gap between connectors 0.100" (2.54mm) to ensure a reliable connection. Product status Obsolete concerning availability and lifecycle. Shielding Unshielded for EMI/RFI protection. Application Socket (0.6"), Board In for defined purpose or objective.
