Description

Sets the ampere rating to 5 A. Provides a DC resistance measurement of 22mOhm Max for accurate circuit operation. Enables a 100 kHz frequency during testing to guarantee accurate device validation. Maximum installed height of 0.083" (2.10mm) for components affixed to the board. Provides 1 µH inductance for circuit tuning and filtering. Assessed for inductance at 100 kHz frequency to verify component reliability. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Strip for safeguarding or transporting components. Style of the enclosure/case Nonstandard that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Shielding Unshielded for EMI/RFI protection. Details on package size 0.157" L x 0.157" W (4.00mm x 4.00mm) for electrical or mechanical components. Measurement dimensions 0.157" L x 0.157" W (4.00mm x 4.00mm) for component specifications. Precision tolerance level ±20% in manufacturing processes.
