Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | CIH03T | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Device Type Classification | Multilayer | |
| Inductor Core Type | - | |
| Coil Inductance Value | 2.7 nH | |
| Accuracy Tolerance Percentage | ±0.3nH | |
| Ampere Capacity Rating | 200 mA | |
| Saturation Current Level | - | |
| Electromagnetic Interference Protection | Unshielded | |
| Direct Current Resistance | 250mOhm Max | |
| Quality Factor at Frequency | 5 @ 100MHz | |
| Self-Resonance Frequency | 7.7GHz | |
| Performance Rating Specs | - | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Test Frequency for Inductance | 100 MHz | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 0201 (0603 Metric) | |
| Vendor Package Type | - | |
| Package Size Specs | 0.024" L x 0.012" W (0.60mm x 0.30mm) | |
| Maximum Mounted Height | - |
Description
Sets the ampere rating to 200 mA. Provides a DC resistance measurement of 250mOhm Max for accurate circuit operation. Features a 7.7GHz self-resonant frequency that enhances component efficiency. Enables a 100 MHz frequency during testing to guarantee accurate device validation. Provides 2.7 nH inductance for circuit tuning and filtering. Assessed for inductance at 100 MHz frequency to verify component reliability. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 0201 (0603 Metric) that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Quality factor at frequency 5 @ 100MHz for resonant systems. Classification series for the product or component CIH03T. Shielding Unshielded for EMI/RFI protection. Details on package size 0.024" L x 0.012" W (0.60mm x 0.30mm) for electrical or mechanical components. Measurement dimensions 0.024" L x 0.012" W (0.60mm x 0.30mm) for component specifications. Precision tolerance level ±0.3nH in manufacturing processes. Type classification Multilayer for specifications.
