Stock:
Distributor: 120
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1835 | ₹ 17.36000 | ₹ 31,855.60 |
| 772 | ₹ 18.69000 | ₹ 14,428.68 |
| 357 | ₹ 21.36000 | ₹ 7,625.52 |
| 104 | ₹ 25.03000 | ₹ 2,603.12 |
| 28 | ₹ 43.39000 | ₹ 1,214.92 |
| 7 | ₹ 66.75000 | ₹ 467.25 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | SA | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Device Type Classification | - | |
| Inductor Core Type | - | |
| Coil Inductance Value | 10 µH | |
| Accuracy Tolerance Percentage | ±10% | |
| Ampere Capacity Rating | 18 mA | |
| Saturation Current Level | - | |
| Electromagnetic Interference Protection | Shielded | |
| Direct Current Resistance | 1.8Ohm Max | |
| Quality Factor at Frequency | 40 @ 5MHz | |
| Self-Resonance Frequency | 30MHz | |
| Performance Rating Specs | - | |
| Ambient Temp Range | - | |
| Test Frequency for Inductance | 1 MHz | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 1210 (3225 Metric) | |
| Vendor Package Type | - | |
| Package Size Specs | 0.126" L x 0.098" W (3.20mm x 2.50mm) | |
| Maximum Mounted Height | 0.094" (2.40mm) |
Description
Sets the ampere rating to 18 mA. Provides a DC resistance measurement of 1.8Ohm Max for accurate circuit operation. Features a 30MHz self-resonant frequency that enhances component efficiency. Enables a 1 MHz frequency during testing to guarantee accurate device validation. Maximum installed height of 0.094" (2.40mm) for components affixed to the board. Provides 10 µH inductance for circuit tuning and filtering. Assessed for inductance at 1 MHz frequency to verify component reliability. Mounting configuration Surface Mount for structural stability. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 1210 (3225 Metric) that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Quality factor at frequency 40 @ 5MHz for resonant systems. Classification series for the product or component SA. Shielding Shielded for EMI/RFI protection. Details on package size 0.126" L x 0.098" W (3.20mm x 2.50mm) for electrical or mechanical components. Measurement dimensions 0.126" L x 0.098" W (3.20mm x 2.50mm) for component specifications. Precision tolerance level ±10% in manufacturing processes.
