Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | NC | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Device Type Classification | Wirewound | |
| Inductor Core Type | Non-Magnetic | |
| Coil Inductance Value | 18 nH | |
| Accuracy Tolerance Percentage | ±10% | |
| Ampere Capacity Rating | 250 mA | |
| Saturation Current Level | - | |
| Electromagnetic Interference Protection | Unshielded | |
| Direct Current Resistance | 400mOhm Max | |
| Quality Factor at Frequency | 10 @ 100MHz | |
| Self-Resonance Frequency | 1.55GHz | |
| Performance Rating Specs | - | |
| Ambient Temp Range | -20°C ~ 85°C | |
| Test Frequency for Inductance | 100 MHz | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 1008 (2520 Metric) | |
| Vendor Package Type | 1008 (2520 Metric) | |
| Package Size Specs | 0.098" L x 0.079" W (2.50mm x 2.00mm) | |
| Maximum Mounted Height | 0.071" (1.80mm) |
Description
Sets the ampere rating to 250 mA. Provides a DC resistance measurement of 400mOhm Max for accurate circuit operation. Features a 1.55GHz self-resonant frequency that enhances component efficiency. Enables a 100 MHz frequency during testing to guarantee accurate device validation. Maximum installed height of 0.071" (1.80mm) for components affixed to the board. Provides 18 nH inductance for circuit tuning and filtering. Assessed for inductance at 100 MHz frequency to verify component reliability. Substance Non-Magnetic to achieve optimal electromagnetic efficiency. Mounting configuration Surface Mount for structural stability. Temperature range -20°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 1008 (2520 Metric) that offers mechanical and thermal protection. Type of package 1008 (2520 Metric) that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Quality factor at frequency 10 @ 100MHz for resonant systems. Classification series for the product or component NC. Shielding Unshielded for EMI/RFI protection. Details on package size 0.098" L x 0.079" W (2.50mm x 2.00mm) for electrical or mechanical components. Measurement dimensions 0.098" L x 0.079" W (2.50mm x 2.00mm) for component specifications. Supplier package type 1008 (2520 Metric) for component selection. Precision tolerance level ±10% in manufacturing processes. Type classification Wirewound for specifications.
