Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | SIMID | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Device Type Classification | Drum Core, Wirewound | |
| Inductor Core Type | Ferrite | |
| Coil Inductance Value | 100 µH | |
| Accuracy Tolerance Percentage | ±10% | |
| Ampere Capacity Rating | 250 mA | |
| Saturation Current Level | - | |
| Electromagnetic Interference Protection | Unshielded | |
| Direct Current Resistance | 1.28Ohm Max | |
| Quality Factor at Frequency | 20 @ 796kHz | |
| Self-Resonance Frequency | 6MHz | |
| Performance Rating Specs | AEC-Q200 | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Test Frequency for Inductance | 796 kHz | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 2-SMD, J-Lead | |
| Vendor Package Type | 2220 (5650 Metric) | |
| Package Size Specs | 0.220" L x 0.197" W (5.60mm x 5.00mm) | |
| Maximum Mounted Height | 0.209" (5.30mm) |
Description
Sets the ampere rating to 250 mA. Provides a DC resistance measurement of 1.28Ohm Max for accurate circuit operation. Features a 6MHz self-resonant frequency that enhances component efficiency. Enables a 796 kHz frequency during testing to guarantee accurate device validation. Maximum installed height of 0.209" (5.30mm) for components affixed to the board. Provides 100 µH inductance for circuit tuning and filtering. Assessed for inductance at 796 kHz frequency to verify component reliability. Substance Ferrite to achieve optimal electromagnetic efficiency. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 2-SMD, J-Lead that offers mechanical and thermal protection. Type of package 2220 (5650 Metric) that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Quality factor at frequency 20 @ 796kHz for resonant systems. Criteria AEC-Q200 for electrical, mechanical, or environmental performance. Classification series for the product or component SIMID. Shielding Unshielded for EMI/RFI protection. Details on package size 0.220" L x 0.197" W (5.60mm x 5.00mm) for electrical or mechanical components. Measurement dimensions 0.220" L x 0.197" W (5.60mm x 5.00mm) for component specifications. Supplier package type 2220 (5650 Metric) for component selection. Precision tolerance level ±10% in manufacturing processes. Type classification Drum Core, Wirewound for specifications.
