Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | SIMID | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Device Type Classification | Drum Core, Wirewound | |
| Inductor Core Type | Ferrite | |
| Coil Inductance Value | 10 µH | |
| Accuracy Tolerance Percentage | ±10% | |
| Ampere Capacity Rating | 690 mA | |
| Saturation Current Level | - | |
| Electromagnetic Interference Protection | Unshielded | |
| Direct Current Resistance | 168mOhm Max | |
| Quality Factor at Frequency | 10 @ 2.52MHz | |
| Self-Resonance Frequency | 19MHz | |
| Performance Rating Specs | AEC-Q200 | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Test Frequency for Inductance | 2.52 MHz | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 2-SMD, J-Lead | |
| Vendor Package Type | 2220 (5650 Metric) | |
| Package Size Specs | 0.220" L x 0.197" W (5.60mm x 5.00mm) | |
| Maximum Mounted Height | 0.209" (5.30mm) |
Description
Sets the ampere rating to 690 mA. Provides a DC resistance measurement of 168mOhm Max for accurate circuit operation. Features a 19MHz self-resonant frequency that enhances component efficiency. Enables a 2.52 MHz frequency during testing to guarantee accurate device validation. Maximum installed height of 0.209" (5.30mm) for components affixed to the board. Provides 10 µH inductance for circuit tuning and filtering. Assessed for inductance at 2.52 MHz frequency to verify component reliability. Substance Ferrite to achieve optimal electromagnetic efficiency. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 2-SMD, J-Lead that offers mechanical and thermal protection. Type of package 2220 (5650 Metric) that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Quality factor at frequency 10 @ 2.52MHz for resonant systems. Criteria AEC-Q200 for electrical, mechanical, or environmental performance. Classification series for the product or component SIMID. Shielding Unshielded for EMI/RFI protection. Details on package size 0.220" L x 0.197" W (5.60mm x 5.00mm) for electrical or mechanical components. Measurement dimensions 0.220" L x 0.197" W (5.60mm x 5.00mm) for component specifications. Supplier package type 2220 (5650 Metric) for component selection. Precision tolerance level ±10% in manufacturing processes. Type classification Drum Core, Wirewound for specifications.
