Description

Sets the ampere rating to 300 mA. Provides a DC resistance measurement of 680mOhm for accurate circuit operation. Features a 1.15GHz self-resonant frequency that enhances component efficiency. Enables a 150 MHz frequency during testing to guarantee accurate device validation. Maximum installed height of 0.041" (1.03mm) for components affixed to the board. Provides 120 nH inductance for circuit tuning and filtering. Assessed for inductance at 150 MHz frequency to verify component reliability. Substance Ceramic to achieve optimal electromagnetic efficiency. Mounting configuration Surface Mount for structural stability. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 0805 (2012 Metric) that offers mechanical and thermal protection. Type of package 0805 that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Quality factor at frequency 40 @ 250MHz for resonant systems. Classification series for the product or component 0805CT. Shielding Unshielded for EMI/RFI protection. Details on package size 0.090" L x 0.068" W (2.29mm x 1.73mm) for electrical or mechanical components. Measurement dimensions 0.090" L x 0.068" W (2.29mm x 1.73mm) for component specifications. Supplier package type 0805 for component selection. Precision tolerance level ±5% in manufacturing processes. Type classification Drum Core, Wirewound for specifications.
