Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 4564 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Device Type Classification | - | |
| Inductor Core Type | Ferrite | |
| Coil Inductance Value | 150 µH | |
| Accuracy Tolerance Percentage | ±10% | |
| Ampere Capacity Rating | 200 mA | |
| Saturation Current Level | - | |
| Electromagnetic Interference Protection | Unshielded | |
| Direct Current Resistance | 2Ohm Max | |
| Quality Factor at Frequency | 80 @ 796kHz | |
| Self-Resonance Frequency | 3.8MHz | |
| Performance Rating Specs | - | |
| Ambient Temp Range | -20°C ~ 80°C | |
| Test Frequency for Inductance | 796 kHz | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Radial, Vertical Cylinder | |
| Vendor Package Type | - | |
| Package Size Specs | 0.340" Dia (8.64mm) | |
| Maximum Mounted Height | 0.433" (11.00mm) |
Description
Sets the ampere rating to 200 mA. Provides a DC resistance measurement of 2Ohm Max for accurate circuit operation. Features a 3.8MHz self-resonant frequency that enhances component efficiency. Enables a 796 kHz frequency during testing to guarantee accurate device validation. Maximum installed height of 0.433" (11.00mm) for components affixed to the board. Provides 150 µH inductance for circuit tuning and filtering. Assessed for inductance at 796 kHz frequency to verify component reliability. Substance Ferrite to achieve optimal electromagnetic efficiency. Mounting configuration Through Hole for structural stability. Temperature range -20°C ~ 80°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Radial, Vertical Cylinder that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Quality factor at frequency 80 @ 796kHz for resonant systems. Classification series for the product or component 4564. Shielding Unshielded for EMI/RFI protection. Details on package size 0.340" Dia (8.64mm) for electrical or mechanical components. Measurement dimensions 0.340" Dia (8.64mm) for component specifications. Precision tolerance level ±10% in manufacturing processes.
