Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 4232 | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Device Type Classification | Drum Core, Wirewound | |
| Inductor Core Type | Iron | |
| Coil Inductance Value | 47 µH | |
| Accuracy Tolerance Percentage | ±1% | |
| Ampere Capacity Rating | 135 mA | |
| Saturation Current Level | - | |
| Electromagnetic Interference Protection | Unshielded | |
| Direct Current Resistance | 11.4Ohm Max | |
| Quality Factor at Frequency | 30 @ 2.5MHz | |
| Self-Resonance Frequency | 10MHz | |
| Performance Rating Specs | - | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Test Frequency for Inductance | 2.5 MHz | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 2-SMD | |
| Vendor Package Type | - | |
| Package Size Specs | 0.138" L x 0.105" W (3.51mm x 2.67mm) | |
| Maximum Mounted Height | 0.101" (2.57mm) |
Description
Sets the ampere rating to 135 mA. Provides a DC resistance measurement of 11.4Ohm Max for accurate circuit operation. Features a 10MHz self-resonant frequency that enhances component efficiency. Enables a 2.5 MHz frequency during testing to guarantee accurate device validation. Maximum installed height of 0.101" (2.57mm) for components affixed to the board. Provides 47 µH inductance for circuit tuning and filtering. Assessed for inductance at 2.5 MHz frequency to verify component reliability. Substance Iron to achieve optimal electromagnetic efficiency. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 2-SMD that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Quality factor at frequency 30 @ 2.5MHz for resonant systems. Classification series for the product or component 4232. Shielding Unshielded for EMI/RFI protection. Details on package size 0.138" L x 0.105" W (3.51mm x 2.67mm) for electrical or mechanical components. Measurement dimensions 0.138" L x 0.105" W (3.51mm x 2.67mm) for component specifications. Precision tolerance level ±1% in manufacturing processes. Type classification Drum Core, Wirewound for specifications.
