Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 750 | ₹ 176.78000 | ₹ 1,32,585.00 |
Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 371.13000 | ₹ 371.13 |
| 10 | ₹ 309.72000 | ₹ 3,097.20 |
| 25 | ₹ 283.02000 | ₹ 7,075.50 |
| 50 | ₹ 242.97000 | ₹ 12,148.50 |
| 100 | ₹ 222.50000 | ₹ 22,250.00 |
| 250 | ₹ 215.38000 | ₹ 53,845.00 |
| 500 | ₹ 202.03000 | ₹ 1,01,015.00 |
| 1000 | ₹ 194.91000 | ₹ 1,94,910.00 |
| 2500 | ₹ 173.55000 | ₹ 4,33,875.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 2510R | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Device Type Classification | - | |
| Inductor Core Type | Ferrite | |
| Coil Inductance Value | 270 µH | |
| Accuracy Tolerance Percentage | ±10% | |
| Ampere Capacity Rating | 35 mA | |
| Saturation Current Level | - | |
| Electromagnetic Interference Protection | Unshielded | |
| Direct Current Resistance | 37Ohm Max | |
| Quality Factor at Frequency | 15 @ 790kHz | |
| Self-Resonance Frequency | 6.2MHz | |
| Performance Rating Specs | - | |
| Ambient Temp Range | -55°C ~ 105°C | |
| Test Frequency for Inductance | 790 kHz | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 2-SMD | |
| Vendor Package Type | - | |
| Package Size Specs | 0.255" L x 0.105" W (6.48mm x 2.67mm) | |
| Maximum Mounted Height | 0.110" (2.79mm) |
Description
Sets the ampere rating to 35 mA. Provides a DC resistance measurement of 37Ohm Max for accurate circuit operation. Features a 6.2MHz self-resonant frequency that enhances component efficiency. Enables a 790 kHz frequency during testing to guarantee accurate device validation. Maximum installed height of 0.110" (2.79mm) for components affixed to the board. Provides 270 µH inductance for circuit tuning and filtering. Assessed for inductance at 790 kHz frequency to verify component reliability. Substance Ferrite to achieve optimal electromagnetic efficiency. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 105°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 2-SMD that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Quality factor at frequency 15 @ 790kHz for resonant systems. Classification series for the product or component 2510R. Shielding Unshielded for EMI/RFI protection. Details on package size 0.255" L x 0.105" W (6.48mm x 2.67mm) for electrical or mechanical components. Measurement dimensions 0.255" L x 0.105" W (6.48mm x 2.67mm) for component specifications. Precision tolerance level ±10% in manufacturing processes.
