Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1000 | ₹ 150.02000 | ₹ 1,50,020.00 |
Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 318.62000 | ₹ 318.62 |
| 10 | ₹ 266.11000 | ₹ 2,661.10 |
| 25 | ₹ 242.97000 | ₹ 6,074.25 |
| 100 | ₹ 191.35000 | ₹ 19,135.00 |
| 250 | ₹ 185.12000 | ₹ 46,280.00 |
| 500 | ₹ 173.55000 | ₹ 86,775.00 |
| 1000 | ₹ 149.52000 | ₹ 1,49,520.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 1537 | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Device Type Classification | Molded | |
| Inductor Core Type | Phenolic | |
| Coil Inductance Value | 560 nH | |
| Accuracy Tolerance Percentage | ±10% | |
| Ampere Capacity Rating | 1.29 A | |
| Saturation Current Level | - | |
| Electromagnetic Interference Protection | Unshielded | |
| Direct Current Resistance | 135mOhm Max | |
| Quality Factor at Frequency | 50 @ 25MHz | |
| Self-Resonance Frequency | 280MHz | |
| Performance Rating Specs | - | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Test Frequency for Inductance | 25 MHz | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Axial | |
| Vendor Package Type | - | |
| Package Size Specs | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | |
| Maximum Mounted Height | - |
Description
Sets the ampere rating to 1.29 A. Provides a DC resistance measurement of 135mOhm Max for accurate circuit operation. Features a 280MHz self-resonant frequency that enhances component efficiency. Enables a 25 MHz frequency during testing to guarantee accurate device validation. Provides 560 nH inductance for circuit tuning and filtering. Assessed for inductance at 25 MHz frequency to verify component reliability. Substance Phenolic to achieve optimal electromagnetic efficiency. Mounting configuration Through Hole for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case Axial that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Quality factor at frequency 50 @ 25MHz for resonant systems. Classification series for the product or component 1537. Shielding Unshielded for EMI/RFI protection. Details on package size 0.156" Dia x 0.375" L (3.96mm x 9.53mm) for electrical or mechanical components. Measurement dimensions 0.156" Dia x 0.375" L (3.96mm x 9.53mm) for component specifications. Precision tolerance level ±10% in manufacturing processes. Type classification Molded for specifications.
