Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | ASMCI-0805 | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Device Type Classification | Multilayer | |
| Inductor Core Type | Ferrite | |
| Coil Inductance Value | 1 µH | |
| Accuracy Tolerance Percentage | ±30% | |
| Ampere Capacity Rating | 300 mA | |
| Saturation Current Level | - | |
| Electromagnetic Interference Protection | Shielded | |
| Direct Current Resistance | 200mOhm | |
| Quality Factor at Frequency | - | |
| Self-Resonance Frequency | 75MHz | |
| Performance Rating Specs | - | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Test Frequency for Inductance | 1 MHz | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 0805 (2012 Metric) | |
| Vendor Package Type | 0805 (2012 Metric) | |
| Package Size Specs | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Maximum Mounted Height | 0.041" (1.05mm) |
Description
Sets the ampere rating to 300 mA. Provides a DC resistance measurement of 200mOhm for accurate circuit operation. Features a 75MHz self-resonant frequency that enhances component efficiency. Enables a 1 MHz frequency during testing to guarantee accurate device validation. Maximum installed height of 0.041" (1.05mm) for components affixed to the board. Provides 1 µH inductance for circuit tuning and filtering. Assessed for inductance at 1 MHz frequency to verify component reliability. Substance Ferrite to achieve optimal electromagnetic efficiency. Mounting configuration Surface Mount for structural stability. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 0805 (2012 Metric) that offers mechanical and thermal protection. Type of package 0805 (2012 Metric) that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Classification series for the product or component ASMCI-0805. Shielding Shielded for EMI/RFI protection. Details on package size 0.079" L x 0.049" W (2.00mm x 1.25mm) for electrical or mechanical components. Measurement dimensions 0.079" L x 0.049" W (2.00mm x 1.25mm) for component specifications. Supplier package type 0805 (2012 Metric) for component selection. Precision tolerance level ±30% in manufacturing processes. Type classification Multilayer for specifications.
